Description

Hikvision’s Interactive Flat Panels (IFPs) are designed to enhance collaboration and interactivity in educational and business environments. Their product lineup includes the Ultra Series, Pro Series, and Value Series, each tailored to specific needs and budgets. Below is a consolidated overview of select models from these series, highlighting their key specifications:

Ultra Series

Model: DS-D5C98RB/B

• Display: 98″ 4K UHD (3840 × 2160) VA panel

• Brightness: 600 cd/m²

• Contrast Ratio: 5000:1 (Static), 30,000:1 (Dynamic)

• Touch: Infrared, up to 50-point multi-touch, ≤2 ms response time

• Operating System: Android 13.0

• Processor: Quad-core Cortex-A76 × 4 (2.4 GHz) + Cortex-A55 × 4 (1.8 GHz)

• Memory/Storage: 8 GB RAM / 128 GB ROM

• Camera: 48 MP photo, 8 MP video, 93.4° field angle

• Microphone: 8-array omni-directional, 12 m voice pickup

• Audio: 2 × 20 W + 25 W built-in speakers

• Connectivity: Wi-Fi 6, Bluetooth 5.1, multiple HDMI, USB, and Type-C ports

• Additional Features: NFC support, light sensor, advanced image and audio processing technologies

Source: Hikvision DS-D5C98RB/B Specifications

Pro Series

Model: DS-D5B55RB/B

• Display: 55″ 4K UHD (3840 × 2160) LED panel

• Brightness: 350 cd/m²

• Contrast Ratio: 4500:1

• Touch: Infrared, 20-point multi-touch, <10 ms response time

• Operating System: Android 8.0

• Processor: 4-core A73 × 2 + A53 × 2, 1.5 GHz

• Memory/Storage: 3 GB RAM / 32 GB ROM

• Camera: 8 MP, 100° field angle

• Microphone: 6-array omni-directional, 8 m voice pickup

• Audio: 2 × 10 W built-in speakers

• Connectivity: Bluetooth 5.0, multiple HDMI, USB, and LAN portsHikvision+5Hikvision+5Hikvision+5

Source: Hikvision DS-D5B55RB/B Specifications

Value Series

Model: DS-D5B75RB/D

• Display: 75″ 4K UHD (3840 × 2160) LED panel

• Brightness: 350 cd/m²

• Contrast Ratio: 5000:1

• Touch: Infrared, up to 45-point multi-touch, <10 ms response time

• Operating System: Android 11

• Processor: A72 × 2 + A53 × 4, 1.8 GHz

• Memory/Storage: 4 GB RAM / 64 GB ROM

• Camera: 8 MP, 120° field angle

• Microphone: 6-array omni-directional, 8 m voice pickup

• Audio: 2 × 16 W built-in speakers

• Connectivity: Wi-Fi, Bluetooth 5.0, multiple HDMI, USB, and LAN ports
