SECUREYE 4 MP IP CCTV DOME CAMERA

SECUREYE 4 MP IP CCTV DOME CAMERA

Description

SECUREYE 4 MP IP CCTV DOME CAMERA SPECIFICATION

Camera:-

Image Sensor: 1/3’’ Progressive Scan CMOS
Min. Illumination: Color: 0.008Lux @F1.2, B/W: 0Lux with IR on
WDR: Super WDR up to 120dB
Lens: 3.6mm @F1.6
Field of View: H74°(3.6mm)
Shutter Time: 1/100000s~1/5s
IR Distance: Up to 20m
Day&Night: ICR Filter Auto Switch

Video:-

Max Image Resolution: 2592*1520
Frame Rate: 20fps(2592×1520),25fps(2304×1296),25fps(1920×1080),25fps(1280×960), 25fps(1280×720), 25fps(704×576)
Video Compression: H.265(HEVC)/H.264/MJPEG
Video Bit Rate: 16Kbps~16Mbps(CBR/VBR Adjustable)
Image Setting: Brightness/Contrast/Saturation/Sharpness

Network:-

Ethernet: 1*RJ45 10M/100M Ethernet Port
Network Storage: NAS(Support NFS, SMB/CIFS)
Protocol: TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS,DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, SIP, IPv6, PPPoE, VLAN

Audio:-

Audio Streaming: Built-in Microphone
Audio Compression: G.711/AAC

System:-

Storage: Support Micro SD/SDHC/SDXC, up to 64G
Advanced Function: Motion Detection, Privacy Masking, Backlight Compensation, 3D-DNR, ROI
SIP/VoIP Support: Yes, Voice & Video-over-IP
Event Trigger: Motion Detection, Network Disconnection, etc.
Event Action: FTP Upload/ SMTP Upload/ SD Card Record/ SIP Phone
System Compatibility: ONVIF Profile S

General:-

Power Supply: PoE
Power Consumption: 2.5W MAX, 5.5W MAX (With IR on)
Weather Proof: Up to IP67 Rating for Weather-resistant
Weight: 500g
